Anytone AT-588 VHF 220-260MHz Vehicle Mounted Mobile Radio Transceiver Anytone AT588

Sale!

Anytone AT-588 VHF 220-260MHz Vehicle Mounted Mobile Radio Transceiver Anytone AT588

Original price was: $287.00.Current price is: $174.00.

& Free Shipping
Quantity Discount (%) Price
1 $174.00
2 - 4 1.15 % $172.00
5 - 9 4.02 % $167.00
10+ 8.05 % $160.00
Guaranteed Safe Checkout

Anytone AT-588 VHF 220-260MHz Mobile Radio,Vehicle Radio AT588 Car Radio

Frequency: VHF 220~260MHz

Function:
Output Power:60W(VHF),45W(UHF)/25W(HF)/10W

100programmable memorized channels+Call channel, the channels can be  marked with letters and digits

CTCSS/DCS/5-Tone decodes and encodes

Four different single-tone pulse frequencies

CTCSS/DCS scan

Compander to reduce noise

Theft alarm

ANI function(DTMF/ANI,5Tone/ANI) PTT ID.

QHM-03 multifunctional microphone with DTMF

Scramble function(option)

Accessories:
Microphone(with DTMF keypad)
Mobile installing bracket
DC power cable with fuse holder
Hardware kits for bracket

Desktop Mic(Option)

AT-588 SPECIFICATION

General
Frequency Range VHF: 220-260MHz
Number of Channels 200 channels
Channel Spacing 25K (Wide Band)  20K(Middle Band)  12.5K (Narrow band)
Phase-locked Step 5KHz,6.25KHz,8.33KHz,10KHz,12.5KHz,15KHz,  20KHz,25KHz,30KHz,50KHz
Operating Voltage 13.8V  DC ±15%
Squelch Carrier/CTCSS/DCS/5Tone/2Tone/DTMF
Frequency Stability ±2.5ppm
Operating Temperature -20°C~+60°C
Dimensions(WxHxD) 145 (W) x 47 (H) x 190 (L)mm
Weight about 1.2Kg
Receiver (ETSI EN 300 086 standard testing )
Wide band Narrow band
Sensitivity (12dB Sinad) ≤0.25μV ≤0.35μV
Adjacent Channel

Selectivity

≥70dB ≥60dB
Intermodulation ≥65dB ≥60dB
Spurious Rejection ≥70dB ≥70dB
Audio Response +1~-3dB(0.3~3KHz) +1~-3dB(0.3~2.55KHz)
Hum & Noise ≥45dB ≥40dB
Audio distortion ≤5%
Audio power output ≥2W@10%
Transmitter (ETSI EN 300 086 standard testing )
Wide band Narrow band
Power Output 60W/25W/10W(VHF) 45W/25W/10W(UHF)
Modulation 16KΦF3E 11KΦF3E
Adjacent Channel

Power

≥70dB ≥60dB
Hum & Noise ≥40dB ≥36dB
Spurious Emission ≥60dB ≥60dB
Audio Response +1~-3dB(0.3~3KHz) +1~-3dB(0.3~2.55KHz)
Audio Distortion ≤5%



Each Set PACKAGE CONTAIN
  • 1x ANYTONE AT-588 VHF Mobile Radio
  • 1x Microphone
  • 1x Mobile Mounting Bracket
  • 1x DC Power Cable
  • 1x Screws, S-Washer,Spare Fuses pack
  • 1x English Manual



Weight 1.2 kg
Dimensions 300 × 400 × 100 cm
