Anytone AT-D578UV III Plus DMR Tri-band Amateur Mobile Radio AM Aircraft Rx with GPS and Bluetooth
VHF/UHF Tri-band Digital/Analog Part 97 DMR Amateur mobile transceiver with 1.77 inch color TFT display Bluetooth, GPS and DMR roaming.
Frequency coverage: AM Aircraft 108-136 MHz Rx, 144-148 MHz Tx, 222-225 MHz Tx, 420-450 MHz Tx and wide band receive.
Includes USB Programming cable and external Bluetooth PTT button.
Key New Features:
- Analog APRS Location Data Receive and Transmit – See what location you and other operators are broadcasting from.
- Air Band Receive – Listen to airplanes and air traffic.
- 500,000 User Contact List Capacity – Fit all DMR users in your radio for years to come.
RoamingBuilt-in DMR Repeater Roaming feature |
APRS / GPS CapableDMR-APRS and Analog APRS Capable (GPS) |
VHF/UHF Tri-BandFull Duplex Receive (V+V,U+U&V+U) w/ two volume controls |
Digital DMR and AnalogFeatures both DMR digital and analog modes on any channel |
High Power Output50W (45W UHF), 25W, 10W, 1.0W selectable TX power outputs |
BluetoothBluetooth connectivity to some devices (see below) |
Programming CableIncludes USB Programming Cable, free software available for download. |
Color TFT Display1.77 inch color TFT screen for Day or Night operation. User changeable display and font colors. |
Tech Specs
| Bluetooth | New Bluetooth feature compatible with many newer car entertainment systems and Bluetooth devices. It cannot be guaranteed that it will work with all of these devices. Anytone will continue improving the Bluetooth function to allow more device and car models in the future. No timeframe for these future Bluetooth updates is available. |
| Roaming | New Built-in Roaming Feature |
| APRS (GPS) | DMR-APRS Tx/Rx and Analog APRS Tx/Rx, (GPS) |
| Additional Memory | Larger (2G) Memory for Future Enhancements |
| Aircraft Receive | 108-136 MHz “AM” Aircraft Receive Feature |
| TFT Display | Background Display and Font Colors are User changeable |
| Digital Monitor | Monitor One or Two Timeslots |
| Zone Select | User Selectable Zones from Keypad |
| Auto RX Mode | Receiver Auto Selects to incoming Digital or Analog Signal |
| GPS | Built-in GPS feature |
| Memory Channels | 4,000 channels |
| DMR Talk Groups | 10,000 |
| Digital Contacts | 500,000 (complete worldwide database from DMR-MARC) |
| Power Levels | VHF (144-148 MHz): 50/25/10/1 Watts, 220 (222-225 MHz) 5/1 Watts, UHF (400-480 MHz): 45/25/10/1 Watts |
| Zones | 250 zones, up to 250 channels per zone. |
| Display | 1.77 inch color TFT Screen with selectable dual channel or single channel display |
| Bandwidth | 12.5 / 25.0 kHz Analog, and 12.5 kHz DMR |
| Import/Export | Enhanced CPS allows direct input and export of channels, digital IDs and talkgroups |
| Amateur Radio | Ideal for Amateur Radio DMR networks and analog frequencies. Software importable worldwide amateur contact database. |
| DMR Compatibility | Supports both Tier I and Tier II operation, making it compatible with DMR repeaters that utilize two-slot TDMA technology |
| Amateur Radio | Also operational on amateur radio DMR networks and analog frequencies. Software importable worldwide amateur contact database. |
| Cross-band Repeat | Built-in Cross-band repeat function |
| Programmable | FCC 47CFR90.203 requires the keypad locked in the shipping configuration. Software keypad unlocking and re-programming are available with the included USB Programming Cable. |
| Speaker Connection | Single and Dual Speaker output |
| Quiet Tones | CTCSS/DCS tone squelch with split tone and custom tone capability |
| Frequency Range | 136-174 MHz Rx, 144-148 MHz Tx / 400-480 MHz Rx, 420-450 MHz Tx / 222-225 MHz Rx/Tx / 108-136 MHz Rx |
| Package Includes | Tri-band VHF/UHF Mobile Radio, Mounting Bracket, Microphone w/ keypad, Bluetooth PTT button and charging cable, free USB Programming cable and downloadable software, 6 ft fused DC power cable, compact GPS antenna with 10 ft. cable and user manual. |
