ICOM IC-7300 HF/50/70MHz short-wave radio station IC-7200 upgraded version genuine products

Special feature:

High -performance real -time spectrum waterfall display system
IC-7300 real-time spectrum range function is at the forefront of the industry in terms of resolution, scanning speed and dynamic range. When you listen to the sound, you can amplify the signal by touching the screen signal by touching the screen signal.

Direct sampling system
The IC-7300 uses a radio frequency direct sampling system, and the radio frequency signal is directly converted to digital data. It is processed in FPGA (Field-ProGramMable Gate Array) so that it can simplify the circuit structure. Amateur radio world, the system is a leading technology.

Audio spectrum function
The audio spectrum function can be used to observe the frequency characteristics of various automatic collected, such as microphones, grades, widths of filters, widths width in continuous mode, and key control waveforms. Whether it is launching or receiving audio, it can be displayed on the screen.

Large touch color TFT LCD display
Large 4.3 -inch color TFT LCD touch screen provides you with intuitive operations. The software keyboard with touch screen can easily set various functions and edit memory content.

Built -in tone
The built -in natural regulator will quickly adjust and change the working frequency band according to the settings of your transmission frequency. This machine has the function of “mandatory tuning” and allows the antenna to be temporarily adjusted.
*Do not use the forced tuning function unless there is an emergency. Otherwise the transmitting power may be reduced.

High performance sound quality
The IC-7300 provides excellent sound quality. IC-7300 is specifically assigned a space on the host aluminum plate to load the speaker to make the sound output a independent unit.

parameter:

Model: ICOM IC-7300

Frequency range: Receive 0.030-74.800MHz (indicator guarantee range: 0.500-29999,50.000-54.000MHz, 70.000-70.500MHz)
Launch 1.800-1.999MHz, 3.500-3.800MHz, 7.000-7.200MHz
10.100-10.150MHz, 14.000-14.350MHz, 18.068-18.168MHz
21.000-21.450MHz, 24.890-24.990MHz, 28.000-29.700MHz
50.000-52.000MHz, 70.000-70.500MHz
*The above is the European version, the frequency range of different versions is different*

Mode: SSB, CW, RTTY, AM, FM

Number of channels: 101

Power: 13.89V DC ± 15%

Size: 240 (w)*94 (h)*238 (d) mm

Weight: about 4.2kg

Delivery content: host, hand microphone, power cord, manual.
