Kydera ​CDR-300UV 20W APRS Dual Band Digital Mobile Radio

Sale!
,

Kydera ​CDR-300UV 20W APRS Dual Band Digital Mobile Radio

$169.00$189.00

& Free Shipping
Guaranteed Safe Checkout

Kydera ​CDR-300UV APRS DMR GPS UHF VHF Dual Band Digital Mobile Radio 20W Vehicle Walkie Talkie

Kydera CDR-300UV 20W Dual Band DMR Mobile Radio Vehicle Car Two way Radio

• Mini Size

• 20W Power

• Dual Band

• CTCSS

• DCS

• Scan

• Definable Side Keys

• VOX

• Hi-Low Power

• Busy Channel Lockout

• Time-Out Timer

• Selectable SQ Level

• CO/TO/SE Scan Switchable



Specification
Model CDR-200UV
Frequency Range(MHz) Tx/Rx:400-480mhz & 136-174mhz
Tx:144-148mhz & 420-450mhz ;  Rx:136-174mhz & 400-480mhz
Type  Dual band, Dual standby
PLL Channel Spacing 5/6.25/10/12.5/25/50/100KHz
Battery Voltage 13.8V ±10%
Antenna Impedance 50Ω
Temperature Range -20℃~+60℃
Frequency Stability ±2.5PPM
Case Size 121.5X65.5X42.5mm
Weight 1500g
Compatible With American Military Standard(MIL-STD-810C/D/E)



Receiver
IFs 51.550Mhz
Sensitivity(12db SINAD) 0.2uV (Wide)/0.25uV (Narrow)
Squelch Selectivity 0.15uV (Wide)/0.2uV (Narrow)
Adjacent Channel Selectivity ≥70dB (Wide)/≥65dB (Narrow)
Intermodulation ≥70dB
Spurious Rejection ≥65dB
Image Rejection ≥70dB
FM Ham And Noise ≤-45dB(Wide)/-40dB (Narrow)
Modulation Type 16KOF3E/11KOF3E
Operating Bandwidth ≤±7KHz/≤±5KHz
AF Output @ 4Ohms ≥2w(8Ω,5% distorition)
Audio Distortion ≤5%



Transmitter
RF Power Output 20W
Modulation Type F3E
Maximum Deviation ≤±5.0KHz(Wide)/≤±2.5KHz (Narrow)
Spurious Emission ≤65dB Below Carrier
Modulation Distortion ≤5%(300-3000Hz)
FM Noise ≤-45dB(W) ≤-40dB(N)

Package Includes:

1 * Kydera CDR-300UV Dual Band DMR Mobile Radio
1 * Handheld Microphone

1 * Mounting bracket & screw
1 * Power cable

1* Programming Cable

Weight 1.8 kg
Dimensions 300 × 400 × 60 cm
Type

Without GPS, With GPS
