QYT KT8900D UHF VHF DUAL BAND MINI Mobile Transceiver with USB Programming Cable

Sale!

QYT KT8900D UHF VHF DUAL BAND MINI Mobile Transceiver with USB Programming Cable

$89.97$143.36

& Free Shipping
Guaranteed Safe Checkout

QYT KT8900D UHF VHF DUAL BAND Two Way Radio Transceiver with USB Programming Cable KT-8900D 15KM Long Range Base Station



Features:
1. Dual band(136~174 Mhz 400~480Mhz ) and Quadstandby(136~174MHz 400~480MHz 220~260MHz 350~390MHz) for amateur use
2. Basic FM radio function, CTCSS DCS PTT ID, DTMF,remote stun adn remote kill
3. Output power: VHF25Watt UHF 20Watt

Specifications:

Item number

KT-8900D

                                                 General

Frequency Range

VHF:136-174MHz   UHF:400-480MHz

Number of Channel

 200

Channel Spacing

25KHz 20K 12.5K

Phase lock step

5KHz, 6.25 KHz, 10 KHz ,12.5 KHz, 15 KHz, 25 KHz

Working Voltage

13.8V DC±15%

Squelch way

CTCSS/DCS/5Tone/2Tone/DTMF

Frequency Stability

±2.5ppm

Operating Temperature

-20℃~+60℃

Dimension(W x H x D)

103(W) x 47(H) x 126(D)mm

Weight

448g

                                                  Receiver

Broadband

Narrow band

Sensitivity

≤ 0.25μV

≤ 0.35μV

Channel choice

≥70dB

≥60dB

Intermodulation

≥65dB

≥60dB

Spurious Rejection

≥70dB

≥70dB

Audio response

+1~ -3dB(0.3~3KHz)

+1~ -3dB(0.3~2.55KHz)

Signal to noise ratio

≥45dB

≥40dB

Audio distortion

≤5%

Audio output power

≥2W@10%

                                                Transmitter

Broadband

Narrow band

Output power

25W/20W(VHF/UHF)

Modulation Mode

16KΦF3E

11KΦF3E

Channel Power

≥70dB

≥60B

Signal to noise ratio

≥40dB

≥36dB

Parasitic harmonic

≥60dB

≥60dB

Audio response

+1~ -3dB(0.3~3KHz)

+1~ -3dB(0.3~2.55KHz)

Audio distortion

≤5%

Specification:
1. Memory Channel: 200
2. Channel Spacing: 25KHz 20K 12.5
3. Frequency Stability: 2.5ppm
4. Operating Temperature: -20C ~ + 60C
5. Operating Voltage: 13.8V DC ± 15%
6. Dimension: 103(W)*47(H)*126(L)mm
7. Weight (with bracket): 1kg
8. Receiver Sensitivity: 0.25V / 0.35V
9. Channel choice:≥70dB /≥60dB
10.Intermodulation: ≥65dB/≥60dB
11.Inter-modulation Rejection: ≥60dB/ ≥65dB
12.Spurious Rejection: ≥70dB /≥70dB
13.Audio Distortion: ≤5%
14.Audio output power:≥2W@10%

Weight 1.5 kg
Dimensions 300 × 400 × 200 cm
