Upgrade version Professional TYT TH-9800 Plus 50W Car Mobile Radio Station


& Free Shipping
Guaranteed Safe Checkout

Upgrade version Professional TYT TH-9800 Plus Pro 50W 809CH Quad Band Dual Display Repeater Scrambler VHF UHF


Programming Software and English User Manual can be sent via Email for free.

Main features :

Quad band transmit and receiver

Cross Band Repeat

Separately Front Panel

809 Memory Channels

DTMF Microphone

Fm Radio 108-135.995MHz

High/Low Output Power Levels

Reverse Frequency Selection

Dual (V/U) Squelch Set Levels

Dual Repeater Offsets Select-Able

Multi Scanning

Repeater Offset

Keypad Lock Function

Channel Name Editing

Ctcss/Dcs Encode/Decode


Model TH-9800
Frequency Range RX only:108-135.995mhz,320-512mhz,
(Cellular Blocked)
TX(FM): 26-33mhz,47-54mhz,136-174MHZ ,
Channel Capacity 809 Channels
Channel Spacing 2.5 /5 /6.25 /10 / 12.5 /15 /20 /25 /50 kHz
Modes of emission F3
Antenna Impedance 50 Ohms,unbalanced (Antenna Duplexer built-in)
Frequency Stability plusmn5PPM@-140℉~+140℉(-10℃~+60℃)
Operating Voltage -4℉~+140℉(-20℃~+60℃)
Operating Temperature Range 13.8VDC (plusmn15%),Negative ground
Current Consumption(Approx) RX:0.5A(Squelched)
Case size(WtimesHtimesD) 140*41.5*168 mm (w/o knobs & connectors)
Weight 1.2kg


output power 50/20/10/5W(29/50/144MHZ),40/20/10/5W(430MHZ)
Modulation Type Variable Reactance
Maximum Deviation Better than -60dB(29MHZ: Better than -50dB)
Modulation Distortion Less than 3%
Microphone Impedance 2kOmega


Circuit Type Double-conversion super-heterodyne
Intermediate Frequency 49.95MHz/450KHz (left band)
38.85MHz/450KHz (right band)
Sensitivity (for 12dB SINAD) Better than 0.2muV
Squelch Sensitivity Better than 0.16muV
Selectivity(-6dB/-60dB) 12KHz/30 KHz
Maximum AF output 2W@8Omega for 5% THD
AF output Impedance 4-16Omega

Package Contents:
  • 1 x TH-9800 Mobile Transceiver
  • 1 x Microphone
  • 1 x Mobile Mounting Bracket
  • 1 x DC Power Cord with Fuse
  • 2 x Spare Fuse 15 A
  • 1 Microphone Clip
  • 1times Screw Sets
  • 1times Remote Front Panel Bracket
  • 1 x English Operating Manual

    1 x Extension Cabl

Weight 1.8 kg
Dimensions 500 × 500 × 150 cm
