Digital Transceiver YAESU FT5D DMR Radios 5W C4FM/FM 144/430MHz Dual Band includes SHB-26 black holster

• – Compact Design and Reliable 5W RF Power Output (Selectable 5W / 2.5W / 1W / 0.3W)
• – High Visibility Full-Color TFT Touch panel Display (*The color of the operating frequency may be selected from White, Blue or Red.)
• – Dual band Simultaneous Receive (V+V / U+U / V+U / U+V) & C4FM/C4FM Standby – Advanced C4FM Digital Mode with AMS (Automatic Mode Select), DG-ID feature and Smart Navigation
• – 1W (1000mW) of loud audio power with C4FM clear and crisp audio quality – Rugged Construction: Robust Rubber Protection / IPX7 Rating Water Protection
• – TOUCH & GO Operation with Activity Monitor
•      ・PMG (Primary Memory Group Activity Monitor)
•      ・CAM (CH Activity Monitor)
• – VFO Band Skip Function
• – Memory Auto Grouping (MAG) Function
• – High Speed Band Scope Function enables monitoring up to 79ch centered on the current VFO frequency (Selectable 79 / 39 / 19ch)
• – Full-Flat back body provides excellent grasp / Quick Release Holster(SHB-26BK) Included
• – Built-in 66ch High-Sensitivity GPS Receiver
• – Built-in Bluetooth® unit and the VOX function support wierless and easy Hands-free operation
• – WIRES-X Portable Digital Node compatible
• – Dual Simultaneos AM/FM Broadcast Reception and 2-channel Monitoring
• – 1200/9600bps APRS® Data Communication
• – Recording Function
• – Micro SD Card Slot (up to 32GB)

Frequency range RX 0.5 – 999.9 MHz
                             TX 144 – 146 MHz, 430 – 440 MHz
Power output 5/2//0.3 W optional
Channel stage 5/6.25/8.33/9/10/12,5/15/20/25/50/100 kHz
Mode of traffic F1D, F2D, F3E, F7W
Drive voltage 7.2 V DC (battery) or external supply
Power consumption 140 mA (reception, monoband)
86 mA (standby)
67 mA (standby with power saving)
2 mA (Auto-power off)
1.6 A (TX 5W 144 MHz)
1.9 A (TX 5W 430 MHz)
Size 62 x 100 x 34 mm without antenna & buttons
Weight 282 g (with standard battery and antenna)

Supplied with:

7.2V 2200mAh Li-Ion battery (SBR-14Li)
Battery charger (SAD-25)
Cable for PC (Non-software)
Rubber antenna
Belt clip (SHB-13)
English user manual
